MaxPlatform Height
|
8000mm
|
|
Min Platform height
|
80mm
|
|
Configuration
|
Open through or front and side entrances
|
|
Speed
|
60mm/s
|
|
Load capacity
|
250KG~350KG
|
|
Control voltage
|
24V/DC
|
|
Power Output
|
1.5KW
|
|
Power Input
|
220V/50HZ/25A (or customized for local power supply)
|
|
Drive System
|
Hydraulic
|
|
Control Mode
|
Inching Switch or Automatic
|
|
Drive Control
|
Self-resetting system
|
|
Overload
|
Protection Over current relay
|
|
Material of Platform
|
Checkered slip-proof aluminum alloy
|
|
Painting
|
Plastic electrostatic spraying
|
|
Guard panel & drivecabinet (framework)
|
Aluminum Alloy / 304 stainless steel
|
|
Operation Panel
|
Polished aluminum Alloy
|
|
Safety Wane WorkingRange
|
75°
|
|
Working Condition
|
Both indoors and outdoors
|
|
Working temperature
|
From -10°~60°C
|
|
Installation
|
Non-pit installation, directly fixed to concrete floor (the concrete
floor below the platform shall not be lower than the ground)
|
|
Control Device
|
Calling box (installed on the wall nearby) and remote
controller(Extra optional)
|
|
Emergency Stop
|
The lifting and lowering process can be stopped immediately
by pressing the emergency button.
|
|
Safety device
|
Safety Interlock
|
Lock the platform when it is out of control
|
| |
SafetySensor
|
The operation must be stopped immediately thesafety edge meets obstacles during operation.
|
| |
Emergencylowering
|
The platform can be lowered by opening
hydraulic valve manually or rolling screw rod.
|
| |
Auto-flap
|
Turn up after lifting
|
